Fully PLC Control Automatic Hydraulic Punching Steel Silo Roll Forming Machine
Product Description
Now, the assembled silo that is composed of galvanized corrugated sheet is widely used for the purpose of commercial grain storage around the world, and our assembled silo corrugated sheet roll forming machine is especially designed to manufacture such steel sheets.
Machine Component
This corrugated sheet roll forming machine consists of several parts, as listed below.
1 . 10T hydraulic decoiler
2 . Straightening machine
3 . Shape forming machine
4 . Punching machine
5 . Curving machine
6 . Hydraulic shear
7 . Hydraulic station
8 . PLC control cabinet
9 . Stacker
Specifications
Applicable material Galvanized sheet
Feeding width 1250mm
Processing thickness 1-5mm
Roller material Ball bearing steel goes through heat treatment and surface finish process.
Main motor power / hydraulic station power 90kW / 75kW
Forming passes 18
Forming speed 1-2 pieces/minute
Machine dimensions 32×8×2.5m
Machine weight 110T
Steel coil width: from 1250 mm to 1500 mm;
Internal diameter of coil: variable, from 470 mm to 620 mm
Maximal out diameter:1600mmOil cylinder dia:120mm
Working speed: 0-15m/min adjustable
Main motor power: 7.5KW AC motor
Hydraulic power: 5.5kw
Speed controlled by frequency converter brand: Yaskawa
De-coiler should be with Loop control and hold down, and with baffle for forbid coil fall down
The decoiler has 4 segments
Material of the profile: 195-235Mpa GI or carbon steel
Thickness range: 0.8-3.0mm
Maximum production speed: not less than 18 meters per minute (for non-perforated profiles, excluding cutting)
Main motor power:60kw, AC motor, motor inside of main machine (Brand: Guomao of China)
Machine Voltage, Frequency, Phase: 380 V, 50 Hz, 3Phase
Roll station:20 stations
Roller material:Gcr15 bearing material chrome plated surface with hardness 58-62 degree ,CNC,
Shaft diameter: ￠150mm material: SAE1045 with quenching and tempering
Transmission: by gear box 200*500(outside is cast iron, surface needed polish and paint. Inside is 60# forge and press metal)
Technique Data
1. Material: galvanized coils
2. Material Thickness: 1.5-3.5mm
3. Forming Station: 18
4. Rolling Machine Working Speed: 12-15m/min
5. Drive System: gear box drive
6. Main motor power: 90Kw
7. Punching mold: 3 sets of punching dies at one time
8. Cutting: hydraulic cutting
9. Hydraulic Power: 55Kw, the pressure 25-30Mpa
10. Total Power: 130Kw
11. Out Table: lift auto stacker
Machine Components
| S.N. | Machine List | Qty |
| 1. | 10 ton hydraulic decoiler | 1 set |
| 2. | Feeding&leveling device | 1 set |
| 3. | Gear box drive system | 1 set |
| 4. | Main forming machine | 1 set |
| 5. | Curving device | 1 set |
| 6. | Hydraulic cutting device | 1 set |
| 7. | Auto stacker 6 meters | 1 set |
| 8. | PLC control system | 1 set |
| 9. | Hydraulic station | 1 set |
Advantage of roll forming machine
1 . Reasonable Price
2 . High Quality
3 . 12 Months Warranty
4 . More Than 10 Years Experience
5 . Durable
6 . Reliable
Working Flow of production line
Decoiler--Feedingwithguide--Straighteningdevice--Mainrollformingmachine--Curving--Outputtable
